LQ-Z1200CS Automatic sheet fed shopping kraft paper bag making machine

Availability:
Quantity:
  • LQ-Z1200CS

  • LQ

LQ-Z1200CS Sheet-feeding Paper Bag Making Machine


14

Performance

LQ-Z1200CS sheet-feeding paper bag making machine (Adopt Italy technology) is suitable for the mass bag production, it is the first choice of medium and top grade handbag device. The product adopts mechanical, electricity, light, gas integration technology, setting a number of its proprietary technology, use the creased sheet paper as raw material, can one-time finish: paper feeding, positioning, top folding, tube forming, gusset forming, square bottom folding and gluing automatic, and then compaction output. The variable speed drive technology, combined with the system of vertical and horizontal creasing, bottom folding realize trackless bag molding process. using the PLC programmable control, frequency control technology to realize the integral multi-dimensional control, more centralized control and single point remote control operating system . with characteristics of good quality and high efficiency, its technology ranks leading level in domestic similar products.


Features

1)Feeder: enhanced pre stack paper feeder to realize non stop paper feeding, greatly save the time to load and adjust raw paper.

2)Front and side guides positioning system

3)Top folding system

4)Both water soluable cold glue and hot melt glue

5)Formation version making gusset system

6)Screw rod to adjust bottom clip system

7)Bottom catch bag roller paper bag fall down alert system

8)Automatic collection system: Automatic counting, convenient to collect bags.+


Specification

Max. sheet (LX W)

1200x600mm

Min. sheet (LX W)

560x300mm

Top folding sheet weight

190g-300g/m2

Traditional sheet weight

120g-300g/m2

Bottom Width

90-180mm

Bag Width

180-430mm

Top Folding Deepth

30-70mm

Total Power

20kw

Machine Size

14800x2400x1800mm

Speed

50-80bags/min

Total Weight

12T

Glue Type

Water soluble cold glue

(hot-melt glue)


Suitable paper


A

B

C

D

E

Max. Size

1200

600

180

430

500

Min. Size

540

300

80

180

250

Kraft paper, art paper

(including film laminated paper)  paper need pre-creasing

80mm bag bottom width is customizable

15


Technological process


16

17
